16 Antennas 5G Signal Jammer DIP Switch CDMA 450Mhz For WIFI GPS

Product Information

Name: World First Handheld 5G Cell Phone Signal Jammer With 16 Band Hidden Antenna Blocking 5G Wi-Fi5G RF Signal Jammer ,12Watt Jamming up to 20m
Model: CKJ-1806P16-5G

Color: Black

Product description:
The latest all-in-one design portable wireless signal Jammer, 16 bands jamming all types of Android phones, Tablets, Smart Phones, iPhones, Win phones etc. that use 2G, 3G, 4G, and CDMA 450Mhz, Block LOJACK GPS, Wi-Fi 5G, Walkie-Talkie UHF/VHF and RF signals like 315, 433, 868 is popular in 2019 and in years to come

Key technical specifications: CKJ-1806P16-5G
Channel  Output port   Frequency range
Band 1: VHF&LOJACK 135-175MHz
Band 2: 4GLTE 700 to 803MHz(American standard) Or 738 to 821MHz (European standard)
Band 3: 5GLow 617 to 685MHz(American standard) Or 1427-1518MHz (European standard)
Band 4: 3G 2110-2170MHZ
Band 5: WIFI5.2G 5125-5350MHz
Band 6: GPSL2L5 1170-1280MHz
Band 7: GSM/CDMA 850-894MHz(American standard) Or 925-960MHz (European standard)
Band 8: 4G2600 2496-2690MHz (American standard) Or 2570 to 2690MHz (European standard)
Band 9: RC315 315MHz
Band 10: RC433/434 433-434MHz
Band 11: 5G3700 3600-3900MHz
Band 12: 5G3500 3400-3600MHz
Band 13: GPSL1/Glonass 1570-1610MHz
Band 14: WIFI2.4G/4G2300/Bluetooth 2345-2500MHz
Band 15: DCS&:PCS 1,805 to 1990MHz
Band 16: WIFI5.8G 5725-5850MHz

Basic Specifications

Jam Signal Type:Full Bands Mobile Phone 5G/4G/3G/2G +WiFi2.4G/5G+ GPSL1-L5 +UHF/VHF Walkie-Talkie+LOJACK+RC433 315 868

Output Power:Total 12W,0.7W each band(add antennas gain more than 16Watt)

Jam Radius:2-20meters

Power Supply:AC110-240V to DC12V

Cooling System:High efficiency aluminum alloy radiator, Build-in 3x cooling fan

Working Time:Built-in battery:7.4V/12000mAh Continue working: more than 2.0+ hours

Product Size:280x130x46 mm(with hidden omni Antenna)

Product Weight: appr.2.0kg

Package Contents:Jammer Host x 1, AC Charger x1, omni antenna x16, Car Charger x1, External high gain antenna x16(option)

Advantages:

The latest hidden antenna handheld design 16 bands all-in-one frequencies blocking all cell phone signals, LOJACK GPS, Wi-Fi, RF signals

12 watt high output power, Jamming range 2 to 20 meters (at-75dBm, depends on signal strength in given area)

Two sets different length antennas used in hidden or have better jamming effect

Battery capacity LCD display (Capacity percentage, working Voltage/Current

ABS Shell with good cooling system with cooling fans inside and bigger hot sink, temperature lower than 50℃

With DIP switch, can turn on/off any signal band without affect other bands

With car charger, 12V DC/AC power supply is also available

With built-in bigger battery, can work more than (2.0+ hours) 120 minutes, Easily repeated charging

OEM customized service:
​Customized for special frequency band , Wi-Fi5G, Wireless Camera 1.2GHz etc
Silkscreen OEM service can be offered

Application:
o It can be applied at meeting rooms, conference rooms, museums, galleries, theatres, concert halls, churches, temples, restaurants, classrooms, training centers, factories, banks, trains, bus and more Places that require silence, confidentiality and information security
o For some locations of special purpose such as hospitals, gas stations and more, please do field test first to make sure no interference happened to the normal operation of their equipment and instrument
