Product Details:
Payment & Shipping Terms:
|
Feature: | High Power 16 Antennas 5G Cell Phone Jammer | Jamming Frequencies: | Mobile Phone 2G 3G 4G 5GNAS,WIFI 2.4G 5.8G |
---|---|---|---|
Antennas: | 16 Omni Antennas | Power Supply: | Build-in AC110 Or 220V To DC24V |
Jamming Range: | 20-80m Radius | Cooling System: | 7 Cooling Fans Inside |
Key technical specifications: CKJ-1803M16-5G Cell Phone Signal Jammer | |||
Channel | Output port | Frequency range | Average out-putting power |
1 | CDMA | 851-894MHz | 40dBm/10W |
2 | GSM | 925-960MHz | 40dBm/10W |
3 | DCS or PCS | 1805-1880 or 1920-1990MHz | 39dBm/8W |
4 | 3G | 2110-2170MHz | 39dBm/8W |
5 | 4G1 LTE | 700-803 or 790-862MHz | 39dBm/8W |
6 | 4G LTE1700 | 1700-1800MHz | 39dBm/8W |
7 | 4G Wimax | 2500-2690 or 2300-2400MHz | 39dBm/8W |
8 | WIFI2.4G | 2400-2500MHz | 37dBm/5W |
9 | GPSL1 | 1570-1580MHz | 37dBm/5W |
10 | GPSL2+L5 | 1170-1280MHz | 37dBm/5W |
11 | GPSL3+L4 | 1370-1390MHz | 37dBm/5W |
12 | 5G600/5G1400 | 617-685/1471-1518MHz | 37dBm/5W |
13 | 5G3400 | 3400-3600MHz | 36dBm/4W |
14 | 5G3600 | 3600-3900MHz | 36dBm/4W |
15 | WIFI5.2G | 5100-5500MHz | 36dBm/4W |
16 | WIFI5.8G | 5500-5900MHz | 36dBm/4W |
Power supply: AC adapter 50 to 60Hz, (110-240V AC-24V DC) | |||
Dimensions: (length ,width, height) 445x 272x 70mm(not Include Antenna) | |||
Packing size: 52x42x12cm Net weight:7kg Gross weight: 8kg | |||
Total power:101W Shielding radius: (20-80) meters At -75dBm Still depends on the strength signal in given area, Shielding radius of VHF/UHF signal about 30meters |
|||
Warranty: one year from delivery date |
